Carbon steel plates are widely used in industrial production and construction. In the field of industrial production, it is mainly used to manufacture industrial structural parts such as automobiles, ships, mechanical equipment, aircraft, rails, and bridges. In the field of construction, carbon steel plates are mainly used in the manufacture of building structures, bridges, tunnels and some heavy equipment.
Carbon steel is divided into low carbon steel, medium carbon steel and high carbon steel according to the carbon content:
Low-carbon steel: carbon content of 0.02% to 0.25%
Medium carbon steel: carbon content of 0.25% to 0.6%
High-carbon steel: carbon content of 0.6% to 2.14%
Steel contains more carbon and becomes harder, so low-carbon steel is used as a steel plate produced by cold rolling that deforms the material at low temperature, and high-carbon steel is used for tools requiring hardness, etc.
| Item | Carbon structural steel plate |
| Standard | ASTM, DIN, ISO, EN, JIS, GB, etc. |
| Material | A36,A53, A283-D, A135-A, A53-A, A106-A, A179-C, A214-C, A192, A226, A315-B, A53-B, A106-B, A178-C, A210-A-1, A210-C, A333-1.6, A333-7.9, A333-3.4, A333-8, A334-8, A335-P1, A369-FP1, etc. |
| Size | Length: 1m-12m, or as required |
| Width: 0.6m-3m, or as required | |
| Thickness: 0.1mm-300mm, or as required | |
| Surface | Clean, blasting and painting according to customer requirement. |
| Package | Standard export package, or as required. |
| Price term | FOB, CIF, CFR, CNF, Ex-work |
| Delivery time | Within 7-15 workdays after receiving deposit or L/C |
| Container size | 20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM |
| 40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM | |
| 40ft HC: 12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
| Item | Material | Thickness | Width | Length |
| MS Hot Rolled Steel Plate | Q235 SS400 A36 | 6-25 | 1500 - 2500 | 4000 - 12000 |
| EN10025 HR Steel Plate | S275 / S275JR ,S355/S355 JR | 6-30 | 1500 - 2500 | 4000 - 12000 |
| Boiler Steel Plate | Q245R , Q345R | 6-40 | 1500-2200 | 4000 - 12000 |
| A516 Gr.60 , A516 Gr.70 | ||||
| Bridge Steel Plate | Q235, Q345, Q370, Q420 | 1.5-40 | 1500-2200 | 4000 - 12000 |
| Ship-building Steel Plate | CCSA/B/C/D/E, AH36 | 2-60 | 1500-2200 | 4000 - 12000 |
| Wear Resistant Steel Plate | NM360, NM400, NM450, NM500, NM550 | 6-70 | 1500-2200 | 4000 - 8000 |
| Corten Steel Plate | SPA-H, 09CuPCrNiA, Corten A | 1.5-20 | 1100-2200 | 3000 - 10000 |
Reliable quality. Flexible order quantities.
As a manufacturer, we provide consistent quality and responsive support for every order.
Large or small, we treat each inquiry with the same attention.
Send us your requirements and receive a quick quotation.
Strict QC System
Tianjin Guoyu Steel controls quality at every stage, from raw material to final check.
Incoming Material Check
Hot-rolled wire rods and billets tested for chemistry, mechanical properties, and surface before use.
Process Check
Rolling and finishing monitored for size accuracy, strength, surface quality, and coating uniformity.
Final Check & Docs
Each batch verified for diameter, length, bendability, strength, and appearance. MTC and reports available on request.
